คำอธิบาย
Specification
Intelligent Analytics
AI By Device : Facial recognition, perimeter protection, motion detection 2.0
AI By Camera : Facial recognition, perimeter protection, throwing objects from building, motion detection2.0, ANPR, VCA
Facial Recognition
Face Attributes : N/A
Facial Detection And Analytics : Face picture comparison, human face capture, face picture search
Face Picture Library : Up to 16 face picture libraries, with up to 5,000 face pictures in total (each picture ≤ 1MB, total capacity ≤ 73MB);Up to 16 face picture libraries, with up to 20,000 face pictures in total (each picture ≤ 4 MB, total capacity ≤ 1 GB)
Facial Detection And Analytics Performance : 1-ch, 4 MP,1-ch, 8 MP
Face Picture Comparison : 2-ch
Motion Detection 2.0
By Device : All channels, 4 MP (when enhanced SVC mode is enabled, up to 8 MP) video analysis for human and vehicle recognition to reduce false alarm
By Camera : All channels
Perimeter Protection
By Device : 1-ch, 4 MP (HD network camera, H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm
By Camera : All channels
Video And Audio
IP Video Input : 4-ch
Incoming Bandwidth : 40 Mbps
Outgoing Bandwidth : 80 Mbps
HDMI Output : 1-ch, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
VGA Output : 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
Video Output Mode : HDMI1/VGA simultaneous output
CVBS Output : N/A
Audio Output : 1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio : 1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
Decoding
Decoding Format : H.265/H.265+/H.264+/H.264
Recording Resolution : 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous Playback : 4-ch
Decoding Capability
AI on : 1-ch@12 MP (30 fps)/1-ch@8 MP (30 fps)/3-ch@4 MP (30 fps)/6-ch@1080p (30 fps)
AI off : 1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p (30 fps)
Stream TypeVideo, Video & Audio
Audio Compression : G.711ulaw/G.711alaw/G.722/G.726/AAC
Network
Remote Connection : 128
APIONVIF (profile S/G) : SDK; ISAPI
Compatible Browser : IE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version
Network Protocol : TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Network Interface : 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Auxiliary Interface
SATA1 SATA interface
CapacityUp to 10 TB capacity for each HDD
USB InterfaceFront panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0
Alarm In/Out4/1;N/A;N/A (4/1 is optional)
Warranty
- 3 Years warranty
