คำอธิบาย
APC Smart-UPS 750VA, Tower, LCD 230V with SmartConnect Port
Max Configurable Power (Watts) 2.7kWatts / 3.0kVA
Output Voltage Note Configurable for 220 : 230 or 240 nominal output voltage
Output Voltage Distortion Less than 5 %
Output Frequency (sync to mains) 50/60 Hz +/- 3 Hz Sync to mains
Other Output Voltages 220 V, 240 V
Topology Line interactive
Waveform type Sine wave
Transfer Time 6 ms typical : 10 ms maximum
Input
Input frequency 50/60 Hz +/- 3 Hz Auto-sensing
Input voltage range for main operations 151 – 302 Adjustable, 160 – 286V
Number of Power Cords 1
Other Input Voltages 220 V, 240 V
Batteries & Runtime
Battery type Lead-acid battery
Typical recharge time 3hour(s)
Replacement Battery RBC43
Expected Battery Life (years) 3 – 5
RBC Quantity 1
Battery Charge Power (Watts) 182 Watts
Physical
Maximum Height 86MM, 8.6CM
Maximum Width 432MM, 43.2CM
Maximum Depth 683MM, 68.3CM
Net Weight 44.28KG
Shipping weight 51.7KG
Shipping Height 254MM, 25.4CM
Shipping Width 600MM, 60.0CM
Shipping Depth 980MM, 98.0CM
Units per Pallet 8.0
Warranty
- 2 Year warranty
Download
Product Datasheet
