Specification
Network Parameters
– 8 × 10/100 Mbps PoE port,1 × 10/100 Mbps RJ45 port
– Port Type RJ45 port, full duplex, MDI/MDI-X adaptive
– Working Mode Standard mode (default); Extend mode
– Standard IEEE 802.3, IEEE 802.3u, IEEE 802.3x
– Forwarding Mode Store-and-forward switching
– High Priority Ports Ports 1 to 2
– MAC Address Table 2 K
– Switching Capacity 1.8 Gbps
– Packet Forwarding Rate 1.339 Mpps
– Internal Cache 1 Mbits
– Ports For Long-Distance Transmission Ports 1 to 8
PoE Power Supply
– PoE Standard IEEE 802.3af, IEEE 802.3at
– PoE Power Pin End-span: 1/2(-), 3/6(+) Mid-span: 4/5(+), 7/8(-) 8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
– PoE Port Ports 1 to 8
– Max. Port Power 30 W
– PoE Power Budget 60 W
Dialing Function
– Long Range Ports 1 to 8: up to 300 m, and the speed rate of the port is 10 Mbps.
General
– Dimensions (W × H × D) 170 mm × 27.6 mm × 93.1 mm (6.7” × 1.1” × 3.7”)
– Shell Metal material, fan-free design
– Gross Weight 0.89 kg (1.96 lb)
– Net Weight 0.35 kg (0.77 lb)
– Operating Temperature –10 °C to 55 °C (14 °F to 131 °F)
– Operating Humidity 5% to 95% (no condensation)
– Storage Temperature –40 °C to 85 °C (–40 °F to 185 °F)
– Storage Humidity 5% to 95% (no condensation)
– Power Supply 48 VDC, 1.35 A
– Power Consumption In Idle 5 W
– Max. Power Consumption 65 W
Approval
– EMC FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 55024: 2010 +A1: 2015); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016)
– Safety UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013)
– Chemistry CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
