Specification
Video And Audio
IP Video Input 4-ch Up to 4 MP resolution
Incoming Bandwidth 40 Mbps
Outgoing Bandwidth 60 Mbps
HDMI Output 1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA Output 1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Video Output Mode HDMI/VGA simultaneous output
Decoding
Decoding Format H.265+/H.265/ H.264+/H.264
Recording Resolution 4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
Synchronous Playback 4-ch
Decoding Capability 4-ch@1080p (25 fps), 2-ch@4 MP (25 fps)
Stream Type Video, Video & Audio
Network
Remote Connection 16
Network Protocol TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP,UPnP™
Network Interface 1, RJ-45 10/100Mbps self-adaptive Ethernet interface
PoE
Interface 4, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Power ≤ 36 W
Standard IEEE 802.3 af/at Auxiliary Interface
SATA 1 SATA interface
Capacity Up to 6TB capacity for each disk
Alarm In/Out N/A
USB Interface Rear panel: 2 × USB 2.0
General
Power Supply 48 VDC, 1 A
Consumption ≤ 10 W
Working Temperature -10 to +55º C (+14 to +131º F)
Working Humidity 10% to 90%
Dimension (W × D × H) 265 × 225 × 48 mm (10.4″ × 8.9″ × 1.9″) ≤ 1 kg (2.2 lb)
Certification
FCC Part 15 Subpart B, ANSI C63.4-2014
CE EN50130-4, EN 61000-3-2,EN 61000-3-3
