คำอธิบาย
BDCOM P3600 Series complies with IEEE802.3ah and PRC Community Industry Standard (YD/T 1475-2006), and fully abides by the CTC2.1/3.0 standard. P3600 Series can automatically discover and work harmoniously with ONUs made by different manufacturers to build efficient EPON solutions.
Technical Parameter
| PON ports | 4 |
| GE uplink | 4 GE TX |
| 10GE uplink | 4 10GE/GE SFP+ |
| Supported GPON SFP module | PX20+, PX20++, PX20+++ |
| RJ45 console | 1 |
| Mini-USB console | 1 |
| DRAM (MB) | 512 |
| Flash (MB) | 32 |
| Backplane (Gbps) | 128 |
| MAC table | 16K |
| IPv4 routing table | 6K |
| IPv6 routing table | 2K |
| Buffer size (MB) | 3 |
| Jumbo frame (KB) | 2 |
| Active VLAN | 4094 |
| Total SVI | 128 |
| Forwarding mode | Store-and-forward |
Features
-
Network Availability
- STP/RSTP/MSTP
BPDU guard
EAPS
-
Management
- CLI, SNMP, Telnet,HTTP/HTTPS
Software upgrade through TFTP/FTP
Debug output
-
Network Security
- Limiting the maximum number of users on each port
Port isolation
Packet storm control
Flow-based ACL access control function
Transmission data encryption on the PON port
-
DHCP Function
- Server/Relay/Client
DHCP snooping
DHCP option 66,67,82
DAI
IP source guard
-
Reliability
- Unidirectional Link Detection (UDLD)
Hot swap of the EPON optical module on the expanded slot
Optical link protection of EPON
Abnormal luminescence ONU detection such as long luminescence
-
QoS
- Backpressure flow control (half duplex)
IEEE 802.3x flow control (full duplex)
IEEE 802.1p, CoS
WRR, SP and FIFO
ONU-based uplink/downlink rate limit
DBA and SLA
-
Layer 3 Function
- Static routing, Ripv1/v2, OSPF
RIP, OSPF,RIPng, OSPFv3
-
Multicast
- IGMP Snooping
Controllable Multicast
-
VLAN
- Port-based VLAN
QinQ and flexible QinQ
-
Standards
- IEEE 802.3ah
YD-T 1475-2006
YD-T 1771-2008
China Telecom EPON Technical Requirement CTC2.1/3.0
IEEE 802.1D/1W, Spanning Tree, RSTP; IEEE 802.1Q, VLAN
IEEE 802.3ad-based LACP
Ethernet-II
Warranty
- 1 Year warranty
