The RG-AirMetro550G-B is a Wireless Bridge Base Station that utilizes the IEEE 802.11ac standard for efficient and reliable communication, operating in the 5 GHz band and supporting 2×2 MIMO technology. Offers 2 Gigabit Ethernet service ports and delivers a maximum wireless rate up to 867 Mbps at 5 GHz for bridging, ensuring more than sufficient bandwidth for delivering point to point (PTP) and point to multi-point (PTMP) services (Max. 1 to 32 PTMP). When mounted vertically, this wireless bridge can be adjusted within a range of ±15 to 20 degrees, while when mounted horizontally, it can be adjusted along with the antenna. The RG-AirMetro550G-B establish a mesh connection with other wireless bridges in 30 seconds by a simple press of the WPS button on this device.
Specifications:
- Radio Design: 2.4 GHz single-stream, 5 GHz dual-stream 2×2 MIMO
- Protocol and Standard: IEEE 802.11 a/b/g/n/ac
- Operating Frequency Bands:
– 2.4 GHz: 802.11 b/g/n: 2.4000 GHz to 2.483 GHz
– 5 GHz: 802.11a/n/ac: 5.150 GHz to 5.350 GHz, 5.470 GHz to 5.725 GHz, 5.725 GHz to 5.850 GHz - Antenna Type: Internal 2.4 GHz PCB onboard antenna and external 5 GHz antenna
- Spatial Streams: 2×2 MIMO
- Data Rate:
– 2.4 GHz: 150 Mbps
– 5 GHz: 867 Mbps - Modulation Technology:
– OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24/36Mbps, 64-QAM@48/54Mbps
– MIMO-OFDM: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM - Receive Sensitivity:
– 11a: -89dBm (6Mbps), -80dBm (24Mbps), -76dBm (36Mbps), -71dBm (54Mbps)
– 11n: -83dBm@MCS0, -65dBm@MCS7, -83dBm@MCS8, -65dBm@MCS15
– 11ac VHT20: -83dBm (MCS0), -57dBm (MCS9)
– 11ac VHT40: -79dBm (MCS0), -57dBm (MCS9)
– 11ac VHT80: -76dBm (MCS0), -51dBm (MCS9) - Max. Transmit Power: ≤ 400 mW (26 dBm) (adjustable)
- Power Step: 1 dBm
- Service Ports: 2× 10/100/1000Base-T auto-negotiation ports, where LAN1/PoE port supports 24V PoE input
- Buttons: 1× reset/WPS button
- LED: 1× system LED, 2× port LED, and 3× signal LED
- Power Supply:
– 24V Passive PoE input (shipped with a 24V PoE adapter)
– 12V-1A DC adapter for DC power input - Max. Power Consumption: ≤ 12W
- Installation: Directly mounted onto an antenna
- IP Rating: IP65
- Flame Rating: UL94V-0
- Certification: CE
- MTBF: > 400000 hrs
Dimensions:
- Unit Dimensions: 200 × 98.5 × 29mm (without mounting bracket)
- Net Weight: 0.4kg
- Package Dimensions (LxWxH): 25.5*21.0*6.0cm
- G. Weight: 0.69kg
Temperature and Humidity Requirements:
- Operating Temperature: -40°C to 80°C (-40°F to 176°F) excluding the power adapter
- Note: When a power adapter is used, the maximum operating temperature for both the device and the power adapter is 60°C (140°F)
- Storage temperature: –40°C to 85°C (–40°F to 185°F)
- Operating Humidity: 5% to 95% RH (non-condensing)
- Storage humidity: 5% to 95% RH (non-condensing)
Package Contents:
- 1x RG-AirMetro550G-B Wireless Bridge BS
- 1x Power Adapter for Passive PoE Input, 24 V, 0.5 A
- 1x Power Cord
- 1x UserManual
- 1x Warranty Card
