![RG-ES226GC-P, [EOL]Reyee 26-Port Gigabit Smart Cloud Mananged PoE Switch](https://www.mnc.co.th/wp-content/uploads/2021/01/RG-ES226GC-P.png)
![RG-ES226GC-P, [EOL]Reyee 26-Port Gigabit Smart Cloud Mananged PoE Switch - Image 2](https://www.mnc.co.th/wp-content/uploads/2021/01/RG-ES226GC-P-2.png)
คำอธิบาย
Model Specifications: RG-ES226GC-P
Ports : 24 10/100/1000 Base-T ports (PoE/PoE+), 1 10/100/1000 Base-T port 2 SFP Base-X ports
Maximum output power per PoE port: 30W
Maximum PoE output power per switch: 370W
Switching capacity: 52Gbps
Packet forwarding rate: 38.688Mpps
Surge protection: Common mode: 4KV
Electrostatic discharge : Air discharge: 6KV Contact discharge: 4KV
Power consumption: ≤400W
Power supply: External power adapter
MAC capacity: 4K
Static MAC address: 16
VLAN: Support 802.1Q VLAN
Port management: Support port status display port traffic statistics
PoE port output power status port duplex negotiation
rate configuration flow control configuration PoE output on/off
Security: Support broadcast storm suppression port speed limit port isolation
L2 features: Support port mirroring loop protection cable detection
Management: Support management and configuration through a web management interface
Ruijie Cloud platform and Ruijie Cloud app
Specification
- Ports 24 x 10/100/1000Base-T PoE+ ports, 2 SFP uplink
- Switching capacity 52 Gbps
- MAC address table 8000
- Fan Built-in
- Dimensions (W x D x H) 440 mm x 289 mm x 43.6 mm
- MTBF > 200,000
- PoE 370W, IEEE 802.3at / IEEE 802.3af
- Forwarding rate 38.69 Mpps
- Maximum VLAN 16
- Port surge 4 kV
- Weight (With package) 4.2 kg
Download
Product Datasheet
